New York Air Brake Co Instruction Pamphlet #5039-4 Sup 1 Single Car Testing Device
Instruction Pamphlet #5039-4 Sup. 1
May 1965
Single Car Testing Device Code of Tests
Spiral Bound
FRONT AND BACK COVER ARE TAPED AND STAPLED - PLEASE VIEW PHOTOS TO ASSESS CONDITION
102 pages
Single Car Testing Device 5
Freight Equipments - Single Capacity
Standard "AB" 10
AB-1-B 16
Freight Equipments - Other Than Standard Single Capacity Strut Cylinder Adjustment 18AB-8 and AB-10 Empty and Load 23 All "AB" Which Include A Supply Reservoir In
Addition to Auxiliary and Emergency Reservoirs . 24 "AB" 7-5/8" x 12" Empty and Load. 24"AB" Empty and Load Which Include Differential
Relay Valve25
AB-4-12 Single Capacity 26All "AB" Single Capacity Which Include Relay Valves 26
General Instructions for Testing and Maintaining the
Freight Single Car Testing Device 29
Positions of Freight Device .31Rotary Valves and Rotary Valve Seats of the Single Car
Testing Devices 33
Passenger Equipment Valves
D-22 Type and 26-C Control
By Means of Standard Device 34 By Means of Alternate Standard Device . .45
Quick Service Universal U-12-B, U-12-BC and U-12-BD
By Means of Standard Device.... .51
By Means of Alternate Standard Device . . . .56U-12 Universal, No. 3 Control and "L" Triple
By Means of Standard Device.....61
By Means of Alternate Standard Device .66Types "P" and "PS" Triple
By Means of Standard Device.. .. .70
By Means of Alternate Standard Device .. ..75
General Instructions for Testing and Maintaining the
Standard Passenger Single Car Testing Device.81
Positions of Standard Device.....84
General Instructions for Testing and Maintaining the AlStandard Passenger Single Car Testing Device. 86 Positions of Alternate Standard Device ....89
Passenger Car Brake Cylinder and Retaining Valve Tests 90
Alternate Method for testing Passenger and Freight
Single Car Testing Devices.......95
Freight Single Car Testing Device Instructions for
Charging Two Cars Simultaneously 98
Quick Opening Diaphragm Cock. 103
|
