Complete Atlas Wiring Book All scales Book #12 Updated for 2008 Soft Cover
The Complete Atlas Wiring Book 56 pages over 100 diagrams
Wiring made easy. Basic, intermediate & advanced techniques
Turnouts, sidings, syes, reverse loops, lighting, turntables, crossings and more
Soft Cover stapled
Copyright 2007
Contents
Introduction 2
Glossary5
Chapter 1- Beginning with the Basics 8
Four parts of layout wiring
Soldering tips
Chapter 2- The Atlas Electrical System 12
Each Atlas electrical component shown and explained
Chapter 3- Turnouts, Switches & Crossings 18
Common rail, power feed and turnouts
Crossings
Switch (turnout) control, switch machine wiring & control box wiring
All rail frogs
Chapter 4- Independent Control of Locomotives - Cab Control 24
Multiple power packs and blocks
Yard Selectors
X-sections
Cab control wiring
Chapter 5- Reversing Loops, Sections & Wyes35
Getting it right the first time
Reversing loops made easy
Length of reversing loops
Two-train operation
The Dog-bone
Wyes
Chapter 6- Using the Snap-Relay45
Powering frogs
Siding control
Selective multiple siding control
Chapter 7- Turntables, Control Panels & Accessories 50
Powering accessories and lights
Signals & panel lamps
Terminal strips & containing wires
